TURCK 200007242 / RI-12H12T-2B1000-12M23 Rotary Position Sensors

Incremental Hollow Shaft Encoder, Industrial Line.

$450.00
Part Numbers
  • RI-12H12T-2B1000-12M23
  • 200007242
Manufactured
Availability
  • Usually ships in 7-10 weeks
Product Specs

Features

  • Incremental Hollow Shaft Encoder
  • Protection class IP67 on housing and shaft side
  • ‐40…+85 °C
  • Max. 6000 rpm (continuous operation 3000 rpm)
  • 10…30 VDC
  • M23 male
  • 12-pin
  • Push-pull
  • with inverted signals
  • Pulse frequency max. 300 kHz
  • 1000 pulses per revolution
Incremental Hollow Shaft Encoder, Industrial Line, Operating voltage 10…30 VDC, Resolution incremental 1000 ppr, Incremental Hollow Shaft Encoder, Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 6000 rpm (continuous operation 3000 rpm), 10…30 VDC, M23 male, 12-pin, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 1000 pulses per revolution
