TURCK 200005575 / RI-10S6S9-2K1024-CA1M Rotary Position Sensors

Incremental Shaft Encoder, Industrial Line.

$450.00
Part Numbers
  • RI-10S6S9-2K1024-CA1M
  • 200005575
Manufactured
Availability
  • Usually ships in 7-10 weeks
Product Specs

Features

  • Servo flange
  • Ø 50.8mm
  • Solid shaft
  • Ø 8mm x 10mm
  • Optical measuring principle
  • Shaft material
  • stainless steel
  • Protection class IP67 on housing and shaft side
  • ‐40…+85 °C
  • Max. 6000 rpm (continuous operation 3000 rpm)
  • 5…30 VDC
  • Cable connection
  • 8-pole
  • Push-pull
  • with inverted signals
  • Pulse frequency max. 300 kHz
  • 1024 pulses per revolution
Incremental Shaft Encoder, Industrial Line, Operating voltage 5…30 VDC, Resolution incremental 1024 ppr, Servo flange, Ø 50.8mm, Solid shaft, Ø 8mm x 10mm, Optical measuring principle, Shaft material, stainless steel, Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 6000 rpm (continuous operation 3000 rpm), 5…30 VDC, Cable connection, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 1024 pulses per revolution
