TURCK 1544903 / RI-12H12T-2B1024-C 1M Encoder Sensors

Incremental Encoder, Industrial Line.

$448.50
Part Numbers
  • RI-12H12T-2B1024-C 1M
  • 1544903
Manufactured
Availability
  • Usually ships in 7-10 weeks
Product Specs

Features

  • Flange with torque stop
  • Ø 50.8 mm
  • Hollow shaft
  • Ø 12 mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • IP67 rated on shaft side
  • ‐30 …+85 °C (with flexible use of cable -20 …+85 °C)
  • Max. 6000 rpm (continuous operation 3000 rpm)
  • 10…30 VDC
  • Cable connection
  • 8-pole
  • Push-pull
  • with inverted signals
  • Pulse frequency max. 300 kHz
  • 1024 pulses per revolution
Incremental Encoder, Industrial Line, Resolution, incremental 1024 ppr, Flange with torque stop, Ø 50.8 mm, Hollow shaft, Ø 12 mm, Optical measuring principle, Shaft material: stainless steel, IP67 rated on shaft side, ‐30 …+85 °C (with flexible use of cable -20 …+85 °C), Max. 6000 rpm (continuous operation 3000 rpm), 10…30 VDC, Cable connection, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 1024 pulses per revolution
