TURCK 1544419 / RM-29S10C-9C28B-R3M12 Encoder Sensors

Absolute Rotary Encoder - Multiturn, Industrial Line.

$2,161.40
Part Numbers
  • RM-29S10C-9C28B-R3M12
  • 1544419
Manufactured
Availability
  • Usually ships in 5-8 weeks
Product Specs

Features

  • Clamping flange
  • Ø 58 mm
  • Solid shaft
  • Ø 10 mm × 20 mm
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP67 on shaft side
  • -40…+80 °C
  • Max. 3000 rpm
  • EtherCAT®
  • Removable bus cover with male
  • 3 × M12
  • Singleturn
  • resolution scalable to 16 bit (default 13-bit)
  • Multiturn resolution max. 12 bit
  • scalable
Absolute Rotary Encoder - Multiturn, Industrial Line, Clamping flange, Ø 58 mm, Solid shaft, Ø 10 mm × 20 mm, Optical measuring principle, Shaft material: stainless steel, Protection class IP67 on shaft side, -40…+80 °C, Max. 3000 rpm, EtherCAT®, Removable bus cover with male, 3 × M12, Singleturn, resolution scalable to 16 bit (default 13-bit), Multiturn resolution max. 12 bit, scalable
