$230.40
  • BI15U-CK40-VP4X2-H1141 W/BS 2.1
  • 15688010
  • Usually ships in 7-10 weeks

Overview

Features

  • Rectangular
  • height 40 mm
  • Variable orientation of active face in 5 directions
  • Plastic
  • PBT‐GF30‐V0
  • High luminance corner LEDs
  • Optimum view on supply voltage and switching state from any position
  • Factor 1 for all metals
  • Protection class IP68
  • Resistant to magnetic fields
  • Extended temperature range
  • High switching frequency
  • DC 4-wire
  • 10…65 VDC
  • Changeover contact
  • PNP output
  • M12 x 1 male connector

Description

Inductive Sensor, Rated switching distance 15 mm, Flush, Rectangular, height 40 mm, Variable orientation of active face in 5 directions, Plastic, PBT‐GF30‐V0, High luminance corner LEDs, Optimum view on supply voltage and switching state from any position, Factor 1 for all metals, Protection class IP68, Resistant to magnetic fields, Extended temperature range, High switching frequency, DC 4-wire, 10…65 VDC, Changeover contact, PNP output, M12 x 1 male connector
