TURCK BIM-PSM-AP6X-0.2-RS4T W/O BKT Magnetic Sensors

Magnetic Field Sensor, For Pneumatic Cylinders.

$135.10
Part Numbers
  • BIM-PSM-AP6X-0.2-RS4T W/O BKT
  • 4625490
Manufactured
Availability
  • Usually ships in 4-6 weeks
Product Specs

Features

  • Rectangular
  • height 18.5 mm
  • Front active face
  • Metal/plastic
  • Al/PA12-GF30
  • Magnetic-inductive sensor
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • Pigtail with male end
  • M12 x 1
Magnetic Field Sensor, For Pneumatic Cylinders, Cable length (L) 0.2 m, Rectangular, height 18.5 mm, Front active face, Metal/plastic, Al/PA12-GF30, Magnetic-inductive sensor, DC 3-wire, 10…30 VDC, NO contact, PNP output, Pigtail with male end, M12 x 1
