$138.10
  • BI5U-Q12-AN6X2/F2
  • 1635539
  • Usually ships in 2-3 weeks

Overview

Features

  • Rectangular
  • height 12mm
  • Active face
  • lateral
  • Plastic
  • PA12‐GF30
  • Factor 1 for all metals
  • Increased switching distance
  • Protection class IP68
  • Resistant to magnetic fields
  • Mountable on metal
  • Shifted oscillator frequency
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • NPN output
  • Cable connection

Description

Inductive Sensor, With Extended Switching Distance, Rated switching distance 5 mm, Cable length (L) 2 m, Flush, Rectangular, height 12mm, Active face, lateral, Plastic, PA12‐GF30, Factor 1 for all metals, Increased switching distance, Protection class IP68, Resistant to magnetic fields, Mountable on metal, Shifted oscillator frequency, DC 3-wire, 10…30 VDC, NO contact, NPN output, Cable connection
