$250.30
  • NI50U-CP40-AP6X2-H1141
  • 1625835
  • Usually ships in 4-6 weeks

Overview

Features

  • Rectangular
  • height 40 mm
  • Variable orientation of active face in 9 directions
  • Plastic
  • PBT‐GF30‐V0
  • High luminance corner LEDs
  • Optimum view on supply voltage and switching state from any position
  • Factor 1 for all metals
  • Increased switching distance
  • Protection class IP68
  • Resistant to magnetic fields
  • Auto-compensation protects against pre-damping
  • Partially embeddable
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • M12 x 1 male connector

Description

Inductive Sensor, With Extended Switching Distance, Rated switching distance 50 mm, Non-flush, Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT‐GF30‐V0, High luminance corner LEDs, Optimum view on supply voltage and switching state from any position, Factor 1 for all metals, Increased switching distance, Protection class IP68, Resistant to magnetic fields, Auto-compensation protects against pre-damping, Partially embeddable, DC 3-wire, 10…30 VDC, NO contact, PNP output, M12 x 1 male connector
