TURCK BI30U-CP40-AP6X2/S10 Inductive Sensors

Inductive Sensor, With Extended Switching Distance.

$193.60
Part Numbers
  • BI30U-CP40-AP6X2/S10
  • 1625825
Manufactured
Availability
  • Usually ships in 5-8 weeks
Product Specs

Features

  • Rectangular
  • height 40 mm
  • Variable orientation of active face in 9 directions
  • Plastic
  • PBT‐GF30‐V0
  • High luminance corner LEDs
  • Optimum visibility of operating-voltage display and switching state in any installation position
  • Factor 1 for all metals
  • Protection class IP68
  • Resistant to magnetic fields
  • Large coverage
  • High switching frequency
  • DC 3-wire
  • 10…30 VDC
  • NO contact
  • PNP output
  • Terminal chamber
Inductive Sensor, With Extended Switching Distance, Rated switching distance 30 mm, Flush, Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT‐GF30‐V0, High luminance corner LEDs, Optimum visibility of operating-voltage display and switching state in any installation position, , Factor 1 for all metals, Protection class IP68, Resistant to magnetic fields, Large coverage, High switching frequency, DC 3-wire, 10…30 VDC, NO contact, PNP output, Terminal chamber
